| 起源の場所: | 中国 |
|---|---|
| ブランド名: | FANRYN |
| パッケージの詳細: | カートン |
| 受渡し時間: | 10営業日 |
| 支払条件: | T/T |
| 水蒸気の伝送速度: | 0.02g/m²・24時間 | 材料: | アルミホイル |
|---|---|---|---|
| 応用: | HVACダクト断熱 | 接着型タイプ: | アクリル |
| 長さ: | 60m | 厚さ: | 0.02mm |
| 炎の拡散指数: | 25 | 涙の強さ: | 8N |
| 喫煙 開発 指数: | 50 | 抗張力: | 40N/25mm |
| 接着強度: | 20N/25mm | 反射率: | 97％ |
| 温度抵抗: | -30℃への120℃ | 幅: | 1.2m |
| ハイライト: | metalized PET woven foil,lightweight reflective aluminum foil,reflective foil for versatile applications |
||
Product Introduction Of The ALUMINUM WOVEN FOIL
Using metalized PET instead of aluminum, this foil offers a lighter alternative while maintaining high reflectivity (95-97%). It is perfect for applications where weight is a concern, such as retrofitting existing roofs or insulating residential villas and restaurants.
Production Details Of The ALUMINUM WOVEN FOIL
Product Parameter Of The ALUMINUM WOVEN FOIL—Aluminum foil / PE woven cloth
|
Aluminum foil / PE woven cloth |
|
|
ITEM |
VALUE |
|
Aluminum thick |
7 micron |
|
Basic weight |
110 gsm |
|
Burst strength |
140 n |
|
Reflectivity |
95~97% |
|
Tensile strength ( MD / XD) |
400 /400 n/25mm |
|
Water soak test |
24 hours no delamination |
|
Service temperature range |
-30 ~ + 60 ℃ |
|
Corrosion |
None |
|
Pliability |
No cracking |
|
Mold and mildew |
No growth |
OTHERS:
Typical width: 0.8m, 1.0m, 1.2m, 1.25m, 1.30m, 1.5m
Length: according to customer request
Inner core: 76mm
Product Parameter Of The ALUMINUM WOVEN FOIL—Aluminum foil / PE woven cloth / Aluminum
|
Aluminum foil / PE woven cloth / Aluminum |
|
|
ITEM |
VALUE |
|
Aluminum thick |
7 micron |
|
Basic weight |
140 gsm |
|
Burst strength |
150 n |
|
Reflectivity |
95~97% |
|
Tensile strength ( MD / XD) |
450 /450 n/25mm |
|
Water soak test |
24 hours no delamination |
|
Service temperature range |
-30 ~ + 60 ℃ |
|
Corrosion |
None |
|
Pliability |
No cracking |
|
Mold and mildew |
No growth |
OTHERS:
Typical width: 0.8m, 1.0m, 1.2m, 1.25m, 1.30m, 1.5m
Length: according to customer request
Inner core: 76mm
Product Parameter Of The ALUMINUM WOVEN FOIL—Metalized PET/ PE woven cloth
|
Metalized PET/ PE woven cloth |
|
|
ITEM |
VALUE |
|
Metalized PET thick |
12 micron |
|
Basic weight |
116 gsm |
|
Burst strength |
110 n |
|
Reflectivity |
95~97% |
|
Tensile strength ( MD / XD) |
450 /450 n/25mm |
|
Water soak test |
24 hours no delamination |
|
Service temperature range |
-30 ~ + 60 ℃ |
|
Corrosion |
None |
|
Pliability |
No cracking |
|
Mold and mildew |
No growth |
OTHERS:
Typical width: 0.8m, 1.0m, 1.2m, 1.25m, 1.30m, 1.5m
Length: according to customer request
Inner core: 76mm
Product Parameter Of The ALUMINUM WOVEN FOIL—Fire retardant aluminum foil / PE woven cloth
|
Fire retardant aluminum foil / PE woven cloth |
|
|
ITEM |
VALUE |
|
Aluminum thick |
7 micron |
|
Basic weight |
110 gsm |
|
Burst strength |
140 n |
|
Reflectivity |
95~97% |
|
Tensile strength ( MD / XD) |
400 /400 n/25mm |
|
Water soak test |
24 hours no delamination |
|
Service temperature range |
-30 ~ + 60 ℃ |
|
Corrosion |
None |
|
Pliability |
No cracking |
|
Mold and mildew |
No growth |
OTHERS:
Typical width: 0.8m, 1.0m, 1.2m, 1.25m, 1.30m, 1.5m
Length: according to customer request
Inner core: 76mm
Product Parameter Of The ALUMINUM WOVEN FOIL—Fire retardant aluminum foil / PE woven cloth / Aluminum
|
Fire retardant aluminum foil / PE woven cloth / Aluminum |
|
|
ITEM |
VALUE |
|
Aluminum thick |
7 micron |
|
Basic weight |
140 gsm |
|
Burst strength |
150 n |
|
Reflectivity |
95~97% |
|
Tensile strength ( MD / XD) |
450 /450 n/25mm |
|
Water soak test |
24 hours no delamination |
|
Service temperature range |
-30 ~ + 60 ℃ |
|
Corrosion |
None |
|
Pliability |
No cracking |
|
Mold and mildew |
No growth |
OTHERS:
Typical width: 0.8m, 1.0m, 1.2m, 1.25m, 1.30m, 1.5m
Length: according to customer request
Inner core: 76mm
Product Feature And Application Of The ALUMINUM WOVEN FOIL
Dual-sided aluminum foil for maximum heat reflection
Higher burst strength (150 N) and tensile strength (450 N/25mm)
Resists delamination even after 24-hour water immersion--
Wide service temperature range (-30℃ to +60℃)
Zero corrosion, cracking, or mold growth
