| 起源の場所: | 中国 |
|---|---|
| ブランド名: | FANRYN |
| 証明: | CE |
| 最小注文数量: | 1つの40 HQ |
| パッケージの詳細: | ビニール袋 |
| 受渡し時間: | 10勤務日 |
| 支払条件: | T/T |
| 応用: | 建築物、産業機器の断熱材 | 材料: | ミネラルウール |
|---|---|---|---|
| 環境への影響: | リサイクル可能で環境に優しい | 製品名: | 断熱ミネラルウール |
| 設置方法: | 機械的固定または接着 | 熱伝導率: | 0.035W/m・K |
| 密度: | 40～200kg/m3 | 圧縮強度: | ≧10kPa |
| 寸法: | ボード、ロール、スラブで入手可能 | 耐熱性: | -268℃～700℃ |
| 吸水性: | <1% | 厚さ範囲: | 25mm～150mm |
| Vaporpermeability: | 0.3 µg/(m·s·Pa) | 耐火性: | 不燃性A1種 |
| 吸音率: | 0.85 | ||
| ハイライト: | rock wool blanket with aluminum foil,vapor barrier reflective insulation,thermal insulation mineral wool blanket |
||
This premium rock wool blanket features a laminated, reinforced aluminum foil facing on one side. The facing acts as a highly effective radiant heat reflector and a certified vapor barrier. It is designed to maximize thermal efficiency by significantly reducing radiant heat transfer and preventing moisture vapor from migrating into the insulation layer, which is critical for controlling condensation in temperature-controlled environments.
| Properties | Blanket | Standards |
|---|---|---|
| Density Tolerance | ±10% | GB/T 19686-2005 |
| Fire Performance | Non-Combustible | GB/T 5464-1999 |
| Reaction to fire Class A1 | GB/T 8624-2006 | |
| Thermal Conductivity (W/mK, at70±5℃) | ≤0.044 | GB/T 10295 |
| Fiber Diameter | 7(+/-1)um | GB/T 5480. 4 |
| Shot Content (shot size＞0.25mm) | ≤12% | |
| Moisture Content | ≤0.5% | |
| Organic Matter Content | ≤4% | |
| Melting Point | ＞1000℃ |
| Product | Blanket |
|---|---|
| Density (kg/m3) | 60-100 |
| Size: L x W (mm) | 600X5000 |
| Thickness (mm) | 30-150 |
Integrated Vapor Barrier: The airtight aluminum foil facing (with appropriate joint sealing) effectively blocks moisture vapor diffusion, protecting the insulation and underlying structures from condensation, mold, and corrosion.
Enhanced Thermal Performance: The reflective foil surface reduces radiant heat gain/loss by up to 97%, complementing the excellent conductive insulation of the rock wool core for superior overall thermal resistance.
Clean & Professional Finish: Provides a neat, finished appearance for interior applications and helps contain fine fibers during installation, improving job-site cleanliness.
Durable & Tear-Resistant: The laminated facing is reinforced with fiberglass scrim for increased durability and tear resistance during handling and installation.
A1: Our experienced QC team will inspect product's quality in every process
A2: Plastic bag + woven bag (Standard Export Packing).
A3: Usual 15-20 work days after placing order
A4: Special product with special specification can be made to order.
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
