Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China
Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China
Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China
基本情報
起源の場所: 中国
ブランド名: FANRYN
証明: CE
モデル番号: ロックウールパイプ
最小注文数量: 仕様ごとに1*40HQ
価格: 0.5-35$/pc
パッケージの詳細: プラスチックのバッグか紙箱
受渡し時間: 15日
支払条件: T/T
供給の能力: 1*40HQ 15日間
ベストプライス 接触
詳細情報
熱伝導性: <=0.044 W/m・K 環境への影響: 再生利用できる、環境に優しい
耐火性: 不燃性A種 水 吸収: <1%
製品名: ロックウールパイプ 応用: 発電所、石油貯蔵所、石油化学工場などの大規模プロジェクトの断熱と耐火。
材料: ロックウール 厚さ: 25-150mm
直径: 22-610mm1
ハイライト:

unfaced rock wool pipe insulation

,

preformed mineral wool pipe cover

,

acoustic stone wool pipe insulation

製品の説明

Products Description

FANRYN Rock Wool Pipe Insulation begins with natural basalt and limestone. These premium rocks are superheated to over 1450°C until molten, then transformed into fine, resilient fibers through a high-speed spinning process. Bonded with a durable thermosetting resin, these inorganic fibers create a robust matrix, which is precision-cut into user-friendly sizes for straightforward, efficient installation.

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 0

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 1

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 2

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 3





Product parameter of the rock wool pipe

Properties

Specifications

Standards

Density Tolerance

±15%

GB/T 19686-2005

Fire Performance

Non-Combustible

GB/T 5464-1999



Reaction to fire Class A1

GB/T 8624-2006

Thermal Conductivity

 (W/mK, at70±5℃)

≤0.044

GB/T 10295

Fiber Diameter

7(+/-1)um

GB/T 5480. 4

Shot Content

(shot size＞0.25mm)

≤12%



Eccentricity of Pipe shell

≤5mm


Product size of the rock wool pipe

DIA

Thickness (mm)

inch

mm

25

30

40

50

60

70

80

90

100

120

150

1/2’’

22

●

●



●















3/4’’

27

●

●

●

●

●

●

●









1’’

34

●

●

●

●

●

●

●









1-1/4’’

43

●

●

●

●

●

●

●

●

●





1-1/2’’

48

●

●

●

●

●

●

●

●

●





2’’

60

●

●

●

●

●

●

●

●

●





2-1/2’’

76

●

●

●

●

●

●

●

●

●





3’’

89

●

●

●

●

●

●

●

●

●





3-1/2’’

108

●

●

●

●

●

●

●

●

●





4’’

114

●

●

●

●

●

●

●

●

●

●



5’’

140



●

●

●

●

●

●

●

●

●

●

6’’

169



●

●

●

●

●

●

●

●

●

●

8’’

219





●

●

●

●

●

●

●

●

●

10’’

273





●

●

●

●

●

●

●

●

●

12’’

325





●

●

●

●

●

●

●

●

●

14’’

356







●

●

●

●

●

●

●

●

15’’

381







●

●

●

●

●

●

●

●

16’’

406







●

●

●

●

●

●

●

●

18’’

456







●

●

●

●

●

●

●

●

19’’

483











●

●

●

●

●

●

20’’

508











●

●

●

●

●

●

22’’

558













●

●

●

●

●

24’’

610













●

●

●

●

●



Product feature of the rock wool pipe

Thermal Efficiency – Delivers outstanding insulation to minimize energy loss.
Fire Safety – Features inherent non-combustibility for enhanced protection.
Acoustic Comfort – Effectively absorbs sound to reduce noise transmission.
Corrosion-Free – Composed of inorganic materials that resist rust and decay.
Eco-Conscious – Made from natural and sustainable materials.
Moisture Resilience – Repels water and inhibits mold growth.
Energy & Emission Savings – Lowers operational energy use and carbon footprint.




Product application

insulation and fireproof of huge projects like power plant, oil depot and petrochemical works.

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 4

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 5

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 6




Main Facing:

Foil-Scrim-Kraft Facing

PVC Facing

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 7





Production packing of the rock wool pipe

Plastic bag or carton.

Acoustic Rock Wool Pipe Unfaced Preformed Mineral Stone Wool Insulation Pipe Cover Rock Wool Pipe in China 8








FAQ:

Q1: How to guarantee the quality of the products?

A1: Our experienced QC team will inspect product's quality in every process



Q2: How to pack exported goods?

A2: Plastic bag (Standard Export Packing).



Q3: what is your lead time for one 40HC container order?

A3: Usual 15-20 work days after placing order.



Q4: What is your advantage on rock wool pipe?

A4: Special product with special specification can be made to order.



Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?

A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
