| 起源の場所: | 中国 |
|---|---|
| ブランド名: | FANRYN |
| 証明: | CE, ASTM E84, EN 13501 12018 |
| モデル番号: | Glasswoolブランケット |
| 最小注文数量: | 仕様ごとに1*40HQ |
| 価格: | 0.2-5$/m2 |
| パッケージの詳細: | 真空ビニール袋+不織布袋 |
| 受渡し時間: | 7～10日 |
| 支払条件: | T/T |
| 供給の能力: | 1*40HQ 7日間 |
| 熱伝導性: | 0.031～0.042W/m・K | 密度: | 10～100kg/m3 |
|---|---|---|---|
| 環境への影響: | 再生利用できる、環境に優しい | 耐火性: | 不燃性A1種 |
| 吸音率: | 1.03 製品反響方法 24kg/m3 2000HZ | 水 吸収: | <1% |
| 製品名: | 断熱材のグラス ウール | 応用: | 建築物、産業機器の断熱材 |
| 厚さ: | 25-200 mm | 材料: | グラスウール |
| 色: | 黄色、茶色、赤 | 温度 抵抗: | -270℃～350℃ |
| 寸法: | さまざま (例: 600x1200 mm ボード) | ||
| ハイライト: | yellow glass wool insulation blanket,sound absorption fiberglass insulation roll,unfaced glass wool insulation blanket |
||
Products Description
Glass wool is an inherently non-combustible material that delivers both thermal and acoustic insulation. When exposed to fire, it does not emit toxic gases, positioning it as one of the most environmentally responsible solutions for insulation across all building services.
Product feature of the red glass wool blanket
Our glass wool blanket is engineered for superior performance and easier handling:
Quick Rebound: Fully restores its intended thickness within 24 hours after removal from vacuum packaging.
Consistent Quality: Offers uniform thickness and color for reliable results.
Stable Form: Provides outstanding dimensional stability for long-term reliability.
Installer-Friendly: Composed of soft, long fibers that significantly reduce dust and fiber fly during construction.
Product Specifications
|
Item |
Unit |
Index |
Standard |
|
Density |
kg/m3 |
10-100 |
GB/T 5480.3-1985 |
|
Average fiber dia. |
µm |
5.5 |
GB/T 5480.4-1985 |
|
Water content |
% |
≤1 |
GB/T 3007-1982 |
|
Grade of combustibility |
|
Non-combustible Grade A |
GB 8624-1997 |
|
Reshrinking temp |
℃ |
≥250 |
GB/T 11835-1998 |
|
Thermal conductibility |
w/m.k |
0.038-0.06 |
GB/T 10294-1988 |
|
Hydrophobicity |
% |
≥98.2 |
GB/T 10299-1988 |
|
Moisture rate |
% |
≤5 |
GB/T 16401-1986 |
|
Sound absorption coefficient |
|
1.03 product reverberation method 24kg/m32000HZ |
GBJ 47-83 |
|
Slag inclusion content |
% |
≤0.3 |
|
Product size of the glass wool blanket
|
Density(kg/m3) |
Thickness(m) |
Length (m) |
Width (m) |
Rolls/packing |
|
|
10-48 |
0.025-0.2 |
5-30 |
0.6 |
2 rolls |
|
|
10-48 |
0.025-0.2 |
5-30 |
1.1 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.15 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.2 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.25 |
1 roll |
2 rolls overlapping |
Product application of the glass wool blanket
Wall Insulation
Steel Structure Insulation
Interior Partition Walls
Railway Carriage Interiors
Acoustic Absorption & Soundproofing
Production Facing For glass wool blanket
Foil-Scrim-Kraft Facing
Alum Glass Cloth Facing
Fiberglass Tissue
Production packing of the glass wool blanket
1. Vacuum plastic bag +woven bag
2. Vacuum plastic bag +woven bag +PE bag
3. Vacuum plastic bag+ PE shrinking bag
4. PE shrinking bag
Note: OEM is acceptable
FAQ:
Q1: How to guarantee the quality of the products?
A1: Our experienced QC team will inspect product's quality in every process
Q2: How to pack exported goods?
A2: Our standard package is Vacuum plastic bag +woven bag (Standard Export Packing).
Q3: What is your lead time for one 40HC container order?
A3: Usual 10-15 work days after placing order.
Q4: What is your advantage on glass wool blanket?
A4: Our glass wool blanket can be freely cut in construction according the shape required.
Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
