ホーム > 製品> ガラス繊維管の隔熱装置> Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic
Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic
Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic
基本情報
起源の場所: 中国
ブランド名: fanryn
証明: GB/T 10294-1988
モデル番号: Glasswoolパイプ
最小注文数量: 1*40hq
価格: 0.1-5$
パッケージの詳細: ビニール袋
受渡し時間: 7〜10日
支払条件: T/T
供給の能力: 10000個
ベストプライス 接触
詳細情報
直径: 18~529mm 耐薬品性: ほとんどの化学物質に耐性があります
音の吸収: 素晴らしい 熱伝導率: 0.031-0.042 w/mk
火災評価: クラスA 材料: グラスファイバー
長さ: 1m 水分率: 5％未満
厚さ: 25-90mm
ハイライト:

foil faced fiberglass pipe insulation

,

high temp HVAC duct insulation

,

acoustic thermal pipe wrap

製品の説明

Product Introduction:

Glass wool pipe insulation sections deliver a cost-efficient thermal solution, acclaimed for their lightweight design and ease of installation. They ensure consistent thermal and acoustic performance across an extensive temperature range (-85°C to 454°C), making them well-suited for diverse applications such as HVAC duct systems, industrial heating setups, residential plumbing, and both hot and cold water pipelines.

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 0


Product parameter of the Industrial Grade Glass wool pipe with aluminum foil facing for  High Temp HVAC




Recommend Thickness List(mm)

Pipeline System Type

The Thickness of glasswood pipe shell applied in different pipeline(mm)

Liquid Temperature Range℃

Diameter of Branches Under 50mm

Under 25mm

32-50

64-100

125-150

Above 200mm

Air System Steaming and Water System High Temperature/
High Pressure System

152-238

40

64

64

75

89

89

Medium Temperature/
Medium Pressure System

122-151

40

50

64

64

75

75

low Temperature/
low Pressure System

94-121

25

40

40

50

50

50

low Temperature System

49-93

13

25

25

40

40

40

Steaming Condensator of Watering System

Any Temperature

25

25

40

50

50

50

Equivalent Thickness of Surface Cooling Prevention

Environment
Temperature

Relative Humidity

System Working Temperature

2℃

7℃

13℃

38℃

50%-60%

25

25

25

70%

40

30

30

80%

75

60

50

85%

100

90

75

32℃

50%-60%

25

25

25

70%

25

25

25

80%

50

50

40

85%

80

75

60

27℃

50%-70%

25

25

25

80%

50

40

30

85%

75

65

50

21℃

50%-70%

25

25

25

80%

50

40

30

85%

75

50

40

If the humidity exceeds 90%, some cooling water will appeared on the surface. In this condition, adding the waterproofing coat or PVC plastic shell if necessary.




Product size of the Industrial Grade Glass wool pipe with aluminum foil facing for High Temp HVAC

Density(kg/m3)

Thickness(mm)

Length (mm)

Diameter (mm)

48-80

25-90

1000,1200

18-529



Product feature and application of Industrial Grade glass wool tube with aluminum foil facing for High Temp HVAC

1.Wide-Ranging Applications
   Ideal for diverse settings such as ventilation ducts, industrial and residential heating systems, and hot and cold water pipelines. Delivers effective thermal and acoustic insulation performance.

2.Comprehensive Performance
   Provides dependable thermal and acoustic insulation across an extensive temperature range (-85°C to 454°C). Combines lightweight properties with straightforward installation.

3.Upgraded Performance with Foil Facing
   The aluminum foil facing enhances moisture resistance, corrosion protection, and thermal reflectivity. Improves overall durability and energy efficiency, making it especially suited for high-humidity and hygiene-critical environments.

4.Economical and Efficient
   A cost-effective solution characterized by low installation and maintenance expenses. Well-adapted for both large engineering projects and everyday applications.

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 1

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 2

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 3

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 4Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 5



Production details of the Industrial Grade glass wool tube with aluminum foil facing for High Temp HVAC

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 6

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 7



Packing and Shipping

Plastic bag

Plastic bag+Carton

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 8

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 9

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 10

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 11

Foil Faced Fiberglass Pipe Insulation High Temp HVAC Duct Mechanical Pipe Wrap Glass Wool Tube for Thermal Acoustic 12


Our Service:

One year warranty for all products

Necessary online technical support

Delivery quality products with excellent service on time

Supply one stop solution on insulation and ventilation products

Supply high level QC service


FAQ:

Q1: How to guarantee the quality of the products?

A1: Our experienced QC team will inspect product's quality in every process



Q2: How to pack exported goods?

A2: Plastic bag (Standard Export Packing).



Q3: what is your lead time for one 40HC container order?

A3: Usual 7-10 work days after placing order



Q4: What is your advantage on glass wool pipe?

A4: Special product with special specification can be made to order.



Q5:About the after-sale service, how to solve the problems occurred of your overseas customer in time?

A5:The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
